Corrugated Box Machine Features

  • Only need 30 seconds to change the order, one person is enough for operating, labour saving.

  • Cardboard size up to 2500mm width with unlimited length, oversized cardboard boxes are available.

  • Have the ability to make dozens of orders with different sizes and different box types every single day.

  • All settings can be entered through a touch screen within 1 minute.

  • No additional tools , servo drive to complete all settings.

  • Powerful motor-driven slitting knives make the edges of the carton more beautiful and flat.

Request Our Latest Catalog

    Corrugated Box Making Machine BM2508-SE

    BM2508-SE is a fully automatic multifunctional box maker with horizontal slotting and scoring, vertical slitting and creasing, horizontal cutting all in one compact machine.

    Compared to BM2508-Plus model, the BM2508-SE model is an economic version machine, which is of great significance to all users under the epidemic. To reduce budget and expenses, it is equipped with a 900mm lead edge feeder, 2 vertical creasing wheels, and removed handhole die cutting module.

    Request An Instant Price

    Corrugated Box Machine Application

    BM2508-SE corrugated box machine is an economic version box making machine, suitable for box plants with small quantity orders and big size cartons, which effectively solves the problem of scattered orders.

    For years, Aopack is committed to providing customized packaging solutions for box plants as well as end-users, which is available for a wide range of many areas, such as furniture, hardware accessories, e-commerce logistics, many other industries, and so on.

    Get Your Solution Now

    Standard Configuration

    • 1 pcs paper feeding bracket
    • 2 pcs 500mm slotting knives
    • 1 pcs horizontal scoring beam
    • 2 pcs vertical creasing wheels (Option 4)
    • 4 vertical slitting knives
    • 1 pcs horizontal cutting knife

    Corrugated Box Making Machine BM2508-SE Specification

    Function BM2508 Plus BM2508 SE BM3000
    Corrugated board type  Sheets Or Fanfold (Single, Double wall)  Sheets (Single, Double wall)  Sheets Or Fanfold (Single, Double wall)
    Cardboard thickness 2-10mm 2-10mm 2-10mm
    Cardboard density range   Up to 1200g/m²   Up to 1200g/m²   Up to 1200g/m²
    Max. board size 2500mm width x unlimited length 2500mm width x unlimited length 3000mm width x unlimited length
    Min. board size 200mm  width x 650mm length 200mm  width x 650mm length 300mm  width x 650mm length
    Production Capacity Appr.7-10 pcs/minute Appr.7-10 pcs/minute Appr.8-12 pcs/minute
    Depends on size and box style. Depends on size and box style. Depends on size and box style.
    Slotting Knife 2 pcs *500mm Length 2 pcs *500mm Length 2 pcs *500mm Length
    Vertical Cutting knife 4 4 4
    Scoring/Creasing wheel 4 2  (Option 4) 4
    Horizontal Cutting knife 1 1 1
    Power supply BM2508-Plus 380V±10%,Max. 7kW, 50/60 Hz BM2508-SE 380V±10%, Max. 6.2kW, 50/60 Hz BM3000 380V±10%, Max. 7.7kW, 50/60 Hz
    Air Pressure 0.6-0.7MPa 0.6-0.7MPa 0.6-0.7MPa
    Dimension 3540(W) * 2050(L)* 2090mm(H) 3370(W) * 1800(L)* 2000mm(H) 3650(W) * 1950(L)* 2090mm(H)
    Gross Weight Appr.3300Kg Appr.2800Kg Appr.3500Kg
    Automatic paper feeding Lead edge feeder 1400mm Lead edge feeder 900mm Lead edge feeder 1400mm
    Handhole on box sides Hand hole module size (120*120mm) NO Hand hole module size (120*120mm)
    Air Consumption 75L/Min 40L/Min 75L/Min
    Box styles More than 60 Fefco codes About 27 (36)Fefco codes More than 60 Fefco codes
    All the above specifications are for reference only.
    The final interpretation right belongs to Qingdao Aopack On Demand Packaging co., Ltd.

    Major Functions Of Corrugated Box Machine BM2508 SE

    Cardboard Feeding

    Cardboard Feeding

    • 20-50 sheets can be loaded, thickness ranging from 10 to 2 mm.
    • A continuous cardboard feeding system with a vacuum pump makes cardboard feeding more accurate.
    Horizontal Slotting & Scoring

    Horizontal Slotting & Scoring

    • Two 500mm symmetrical slotting knives
    • Slotting knife and creasing beam integrated design
    Vertical Scoring & Slitting

    Vertical Scoring & Slitting

    • 4 Vertical slitting knives,  rotated by the servo motor to make the side of the carton box  more beautiful and flat
    • 2 Creasing wheels (Option 4)
    Cross Cutting System

    Cross Cutting System

    • Cut off extra cardboard without an additional paper separator
    Die Cutting System

    Die Cutting System

    • Hand hole, vent hole, special-shaped rounded corners.
    • Cheap module and easy to replace.
    • To reduce budget, BM2508-SE has removed this module.
    Inline Gluing System

    Inline Gluing System

    • Inline cold gluing auto application, no need for extra gluing machine.
    • Highest efficiency and versatility.

    Corrugated Box Making Machine BM2508 SE Workflow

    Corrugated Box Making Machine BM2508 SE Workflow

    More than 100 box styles for your choice

    Corrugated Box Machine Manufacturer FAQs

    Service will be online, we have a full set of manuals, instructions, and guide videos for installation. During Covid, we have guided many customers to get the machine done by themselves. This machine is not complicated, easy to install and put into production within one day. There is also online training for your operators.

    Yes, our BM2508 Plus machine can provide an optional hand hole punching module.

    The normal delivery time is 20 days from deposit, if it is a legal holiday, it will be postponed accordingly.

    Consumable parts that usually suggested is slitting knife and fiber comb, which needs to be replaced every six months or a year.

    We offer one year of warranty from the date of installation.

    We have the CE certification, and the third-party inspection company SGS provides inspection services.

    Yes, when there is a program update, we will inform our customer of the programming update.
